Created with Pixso. Yamaha Gasoline Hydraulic Pump Unit 80Mpa 1.6L/min Piston Pump

Yamaha Gasoline Hydraulic Pump Unit 80Mpa 1.6L/min Piston Pump

الاسم التجاري: XINYA
رقم النموذج: جي واي بي-80-2Q
مو: 1
السعر: $1,500-2,000
معلومات تفصيلية
مكان المنشأ:
جيانغسو ، الصين
التدفق المقدر:
1.6 لتر/دقيقة
الضغط المقدر:
80 ميجا باسكال
أقصى ضغط للإخراج:
100mpa
حجم الخزان:
8L
قوة المحرك:
1.5kw
بناء:
مضخة المكبس
مصدر الطاقة:
هيدروليكي
نوع الوقود:
الغازولين
شوط المحرك:
4 السكتة الدماغية
نوع الأسطوانة:
اسطوانة واحدة
نمط التبريد:
مبرد بالهواء
START SYSTEM:
انطلاق
النزوح:
250 سم مكعب
نظام البدء:
ابدأ الارتداد/المفتاح الكهربائي
الاستخدام:
زيت
إبراز:

Yamaha gasoline hydraulic pump,80Mpa piston pump unit,1.6L/min hydraulic crimping tool

,

80Mpa piston pump unit

,

1.6L/min hydraulic crimping tool

وصف المنتج
Yamaha High-Pressure Hydraulic Pump Unit with Piston Pump Structure Gasoline Engine
Yamaha Gasoline Hydraulic Pump Unit 80Mpa 1.6L/min Piston Pump 0 Yamaha Gasoline Hydraulic Pump Unit 80Mpa 1.6L/min Piston Pump 1
Yamaha Gasoline Engine Hydraulic Unit
Application

This Yamaha Gasoline Engine Hydraulic Unit provides power for cutting tools, hydraulic compressors, punching machines, and other construction machinery. It is designed for operation in field applications across electric power, railway, rescue, and construction industries.

Yamaha Engine Features
  • Small power Yamaha engine
  • Low vibration and low noise operation
  • Easy to operate with high safety standards
  • Precise machining technique
  • Long machine life
  • Delicate and beautiful appearance design
  • Broader applicable scope
  • Good quality with minimal malfunctions
Specifications
  • Fuel: Gasoline
  • Stroke: 4 stroke
  • Cylinder: Single Cylinder
  • Cooling Style: Air-cooled
  • Start: Kick Start
  • Displacement: 250cc
  • Starting System: Recoil/Electric Key start
Technical Data for Yamaha Gasoline Engine Hydraulic Unit
Product NO. Type NO. Rated Pressure (Mpa) Rated Flow (L/min) Max output pressure (Mpa) Tank Volume (L)
80043 JYB-80-2Q 80 1.6 100 8
Yamaha Gasoline Hydraulic Pump Unit 80Mpa 1.6L/min Piston Pump 2 Yamaha Gasoline Hydraulic Pump Unit 80Mpa 1.6L/min Piston Pump 3 Yamaha Gasoline Hydraulic Pump Unit 80Mpa 1.6L/min Piston Pump 4 Yamaha Gasoline Hydraulic Pump Unit 80Mpa 1.6L/min Piston Pump 5 Yamaha Gasoline Hydraulic Pump Unit 80Mpa 1.6L/min Piston Pump 6 Yamaha Gasoline Hydraulic Pump Unit 80Mpa 1.6L/min Piston Pump 7 Yamaha Gasoline Hydraulic Pump Unit 80Mpa 1.6L/min Piston Pump 8
For Pricing and Quotations

Please provide the following information in your enquiry:

  • Rated Pressure (Mpa)
  • Rated Flow (L/min)
  • Max output pressure (Mpa)
  • Quantity required

We will provide you with a competitive price after confirming these details.

Contact us by phone or email for more information about our products.
